LottieSwipeRefreshLayout

12 February 2021 · 1 min read

Originally published on Medium in February 2021. It was written in 2021, so library versions and APIs may have changed since; check current docs before copying code.

I was looking for a way to show a custom animated indicator instead of the default spinner SwipeRefreshLayout from AndroidX.

So I utilised the animations from Lottie and created my own CustomSwipeRefreshLayout.

LottieSwipeRefreshLayout is a a custom SwipeRefreshLayout that shows a Lottie View on top instead. The main idea was to make it as similar to the AndroidX SwipeRefreshLayout as possible, so that they are easily interchangable.

Basic usage

A LottieSwipeRefreshLayout accepts only one child. See example for more detail.

<?xml version="1.0" encoding="utf-8"?>
<com.nabilmh.lottieswiperefreshlayout.LottieSwipeRefreshLayout xmlns:android="http://schemas.android.com/apk/res/android"
                                       xmlns:app="http://schemas.android.com/apk/res-auto"
                                       android:id="@id/swipe_refresh"
                                       android:layout_width="match_parent"
                                       android:layout_height="match_parent"
                                       app:lottie_rawRes="@raw/pull_to_refresh"
                                       >

    <android.support.v7.widget.RecyclerView
        android:id="@+id/recyclerView"
        android:layout_width="match_parent"
        android:layout_height="match_parent"/>

</com.nabilmh.lottieswiperefreshlayout.LottieSwipeRefreshLayout>

Attributes

max_offset_top: The maximum distance in dp that the refresh indicator can be pulled beyond its resting position.

indicator_overlay: Whether to overlay the indicator on top of the content or not (default:true)

trigger_offset_top: The offset in dp from the top of this view at which the progress indicator should come to rest after a successful swipe gesture.

lottie_rawRes: The Lottie file to use. (placed in the raw folder)

Extensible

You can use the base SimpleSwipeRefreshLayout to make your own pull to refresh view.

How to add the library

Add it in your root build.gradle at the end of repositories:

allprojects {
	repositories {
		...
		maven { url 'https://jitpack.io' }
	}
}

Step 2. Add the dependency

dependencies {
        implementation 'com.github.nabil6391:LottieSwipeRefreshLayout:1.0.0'
}

Dont forget to star my library in github

https://github.com/nabil6391/LottieSwipeRefreshLayout

Inspiration

This library took its original inspiration from https://github.com/timrijckaert/LottieSwipeRefreshLayout

Update, October 2026

This one is about the View-based SwipeRefreshLayout. If you are on Compose, see the Compose version, and note that Accompanist's swipe refresh has since been deprecated in favour of the Material pull-to-refresh APIs.
